Product Features :
- The NR200P boasts larger ATX chassis features while retaining a space-efficient form factor.
- The NR200P comes with a choice of side panels: vented steel for unrestricted airflow, or crystal-clear tempered glass to reveal the beauty of a computing beast.
- A PCI Riser is included for vertical GPU installation, ideal for showcasing or feeding it fresh air from the side with the vented panel.
- The NR200P bears unlimited cooling potential: including two 120mm SickleFlow fans, and capable of holding up to 7 fans in total. The compact structure can efficiently house CPU coolers up to 155mm in height and radiators up to 280mm in length, so even the hottest running hardware can’t be held back.
- The NR200P bears unlimited cooling potential: including two 120mm SickleFlow fans, and capable of holding up to 7 fans in total. The compact structure can efficiently house CPU coolers up to 155mm in height and radiators up to 280mm in length, so even the hottest running hardware can’t be held back.
- Triple slot GPUs supports a maximum length of 330mm and maximum width of 156mm, fitting the largest, high-end graphics cards.
- A custom-sized riser cable is included to vertically showcase a graphics card, or allow radiator mounting at the bottom of the chassis to keep the system running as cool as it looks.
- All external panels, including the tempered glass and top mounted fans are secured with pins for easy removal, facilitating quick access to the internals without the use of tools.
Product details:
- Model Number : Cyan: MCB-NR200P-ACNN-S00 / Purple: MCB-NR200P-PCNN-S00 / Pink: MCB-NR200P-QCNN-S00
- Size : MINI-ITX
- Dimensions (L x W x H): 376 x 185 x 292 mm
- Weight: 5.93 Kg
- Motherboard Support: Mini-ITX | Mini-DTX
- Expansion slots: 3
- Hard disk (HDD) support: 1
- Card Support (SSD) : 2 (MAX. 3)
- I/O Panel : 2 x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Audio Jack (Audio+Mic)
- Pre-installed fans : 2x 120mm (SicleFlow PWM Fan)
- Fan Support - Top: 2x 120mm
- Fan Support - Side: 2x 120mm, 2x 140mm
- Fan Support - Rear: 1x 92mm
- Fan Support - Bottom : 2x 120m (Recomendedslim fans for GPUs wider than 2.5 PCI slots)
- Radiator Support - Top : N/A
- Radiator Support - Side : 120mm, 140mm, 240mm, 280mm
- Radiator support Bottom: 120mm, 140mm
- Maximum height of CPU cooler: 76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
- Power Supply Support (PSU): SFX, SFX-L. 130mm
- Graphics card support: L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
