MSI PRO Z790-A MAX WIFI, LGA1700 Socket For intel CPUs Motherboard

• PRO Z790-A MAX WIFI offers a simple design with a harmonious silver color scheme that perfectly matches white and black PC builds. It is engineered with many exclusive features of MSI, a convenient Wi-Fi 7 solution, and DDR5 optimization for Intel Core 14th Gen and 13th Gen processors.

Product Details :

CPU :

• Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors LGA 1700

Memory :

• 4 × DDR5 UDIMM, Maximum Memory Capacity 256GB
• Supports Intel XMP3.0 OC
• Supports Dual-Controller Dual-Channel mode

expansion Slot :

• 1x PCI-E 5.0 x16 slot
• 1x PCI-E 3.0 x1 slot
• 2x PCI-E 4.0 x16 slot

Storage :

• 4 x M.2 slots supporting PCIe Gen4 x4
• 6 x SATA 6G

USB :

• 2x USB 2.0 (Rear)
• 4x USB 2.0 (Front)
• 4x USB 5Gbps Type A (Rear)
• 2x USB 5Gbps Type A (Front)
• 3x USB 10Gbps Type A (Rear)
• 1x USB 10Gbps Type C (Front)
• 1x USB 20Gbps Type C (Rear)

LAN :

• Intel 2.5Gbps LAN

Wireless/Bluetooth :

• Wi-Fi 7
• Supports Bluetooth 5.4

Audio :

• Realtek ALC4080 Codec
• 7.1-Channel USB High Performance Audio

Back I/O Panel Ports :

1. DisplayPort
2. USB 2.0
3. 2.5G LAN
4. Wi-Fi / Bluetooth
5. Audio Connectors
6. HDMI™
7. Flash BIOS Button
8. USB 3.2 Gen 1 5Gbps (Type-A)
9. USB 3.2 Gen 2 10Gbps (Type-A)
10. USB 3.2 Gen 2x2 20Gbps (Type-C)
11. S/PDIF-OUT

Motherboard Size :

• ATX 243.84×304.8 mm

Product Number:

• 911-7E07-024
